ILLINOIS POLLUTION CONTROL BOARD

Section 742.TABLE A: Soil Saturation Limits (C_sat)for Chemicals Whose Melting Point is Less than 30 ° C

CAS No.	Chemical Name	C_sat (mg/kg)
67-64-1	Acetone	100,000
71-43-2	Benzene	870
111-44-4	Bis(2-chloroethyl)ether	3,300
117-81-7	Bis(2-ethylhexyl)phthalate	31,000
75-27-4	Bromodichloromethane (Dichlorobromomethane)	3,000
75-25-2	Bromoform	1,900
71-36-3	Butanol	10,000
85-68-7	Butyl benzyl phthalate	930
75-15-0	Carbon disulfide	720
56-23-5	Carbon tetrachloride	1,100
108-90-7	Chlorobenzene (Monochlorobenzene)	680
124-48-1	Chlorodibromomethane (Dibromochloromethane)	1,300
67-66-3	Chloroform	2,900
96-12-8	1,2-Dibromo-3-chloropropane	1,400
106-93-4	1,2-Dibromoethane (Ethylene dibromide)	2,800
84-74-2	Di-n-butyl phthalate	2,300
95-50-1	1,2-Dichlorobenzene (o-Dichlorobenzene)	560
75-34-3	1,1-Dichloroethane	1,700
107-06-2	1,2-Dichloroethane (Ethylene dichloride)	1,800
75-35-4	1,1-Dichloroethylene	1,500
156-59-2	cis-1,2-Dichloroethylene	1,200
156-60-5	trans-1,2-Dichloroethylene	3,100
78-87-5	1,2-Dichloropropane	1,100
542-75-6	1,3-Dichloropropene (1,3-Dichloropropylene, cis + trans)	1,400

CAS No.	Chemical Name	C_sat (mg/kg)
84-66-2	Diethyl phthalate	2,000
117-84-0	Di-n-octyl phthalate	10,000
100-41-4	Ethylbenzene	400
77-47-4	Hexachlorocyclopentadiene	2,200
78-59-1	Isophorone	4,600
74-83-9	Methyl bromide (Bromomethane)	3,200
1634-04-4	Methyl tert-butyl ether	8,800
75-09-2	Methylene chloride (Dichloromethane)	2,400
98-95-3	Nitrobenzene	1,000
100-42-5	Styrene	1,500
127-18-4	Tetrachloroethylene (Perchloroethylene)	240
108-88-3	Toluene	650
120-82-1	1,2,4-Trichlorobenzene	3,200
71-55-6	1,1,1-Trichloroethane	1,200
79-00-5	1,1,2-Trichloroethane	1,800
79-01-6	Trichloroethylene	1,300
108-05-4	Vinyl acetate	2,700
75-01-4	Vinyl chloride	1,200
108-38-3	m-Xylene	420
95-47-6	o-Xylene	410
106-42-3	p-Xylene	460
1330-20-7	Xylenes (total)	~~410~~320
	Ionizable Organics
95-57-8	2-Chlorophenol	53,000

(Source: Amended in R00-19(B) at 24 Ill. Reg. ____, effective____________________)

(Source: Amended in R00-19(B) at 24 Ill. Reg. ____, effective__________________)

Section 742.TABLE G: Concentrations of Inorganic Chemicals in Background Soils

TABLE H: Chemicals Whose Tier 1 Class I Groundwater Remediation Objective Exceeds the 1 in 1,000,000 Cancer Risk Concentration

(Source: Amended in R00-19(B) at 24 Ill. Reg. ____, effective____________________)

Section 742.TABLE A: Tier 1 Soil Remediation Objectives^a for Residential Properties

Section 742.Table B: Tier 1 Soil Remediation Objectives^a for Industrial/Commercial Properties

83-32-9	Acenaphthene	120,000^b	-----^c	120,000^b	-----^c	570^b	2,900	*
67-64-1	Acetone	200,000^b	100,000^d	200,000^b	100,000^d	16^b	16	*
15972-60-8	Alachlor^o	72^e	-----^c	1,600^e	-----^c	0.04	0.2	NA
116-06-3	Aldicarb^o	2,000^b	-----^c	200^b	-----^c	0.013	0.07	NA
309-00-2	Aldrin	0.3^e	6.6^e	6.1^b	9.3^e	0.5^e	2.5	0.94
120-12-7	Anthracene	610,000^b	-----^c	610,000^b	-----^c	12,000^b	59,000	*
1912-24-9	Atrazine^o	72,000^b	-----^c	7,100^b	-----^c	0.066	0.33	NA
71-43-2	Benzene	100^e	~~1.5~~1.6^e	2,300^e	~~2.1~~2.2^e	0.03	0.17	*

56-55-3	Benzo(a)anthracene	8^e	-----^c	170^e	-----^c	2	8	*
205-99-2	Benzo(b)fluoranthene	8^e	-----^c	170^e	-----^c	5	25	*
207-08-9	Benzo(k)fluroanthene	78^e	-----^c	1,700^e	-----^c	49	250	*
50-32-8	Benzo(a)pyrene	0.8^e	-----^c	17^e	-----^c	8	82	*
111-44-4	Bis(2-chloroethyl)ether	5^e	0.47^e	75^e	0.66^e	0.0004^e,f	0.0004	0.66
117-81-7	Bis(2-ethylhexyl)phthalate	410^e	31,000^d	4,100^b	31,000^d	3,600	31,000^d	*
75-27-4	Bromodichloromethane (Dichlorobromomethane)	92^e	3,000^d	2,000^e	3,000^d	0.6	0.6	*
75-25-2	Bromoform	720^e	100^e	16,000^e	140^e	0.8	0.8	*
71-36-3	Butanol	200,000^b	10,000^d	200,000^b	10,000^d	17^b	17	NA
85-68-7	Butyl benzyl phthalate	410,000^b	930^d	410,000^b	930^d	930^d	930^d	*
86-74-8	Carbazole	290^e	-----^c	6,200^e	-----^c	0.6^e	2.8	NA

1563-66-2	Carbofuran^o	10,000^b	-----^c	1,000^b	-----^c	0.22	1.1	NA
75-15-0	Carbon disulfide	200,000^b	720^d	20,000^b	9.0^b	32^b	160	*
56-23-5	Carbon tetrachloride	44^e	0.64^e	410^b	0.90^e	0.07	0.33	*
57-74-9	Chlordane	41.6^e	38140^e	12100^b	~~53^e~~ 22^b	10	48	*

50-29-3	DDT	17^e	1,500^e	100^b	2,100^e	32^e	160	*
53-70-3	Dibenzo(a,h)anthracene	0.8^e	-----^c	17^e	-----^c	2	7.6	*
96-12-8	1,2-Dibromo-3-chloropropane	4^e	17^b	89^e	0.11^b	0.002	0.002	*
106-93-4	1,2-Dibromoethane (Ethylene dibromide)	0.07^e	0.32^e	1.5^e	0.45^e	0.0004	0.004	0.005
84-74-2	Di-n-butyl phthalate	200,000^b	2,300^d	200,000^b	2,300^d	2,300^d	2,300^d	*
95-50-1	1,2-Dichlorobenzene (o - Dichlorobenzene)	180,000^b	560^d	18,000^b	310^b	17	43	*
106-46-7	1,4-Dichlorobenzene (p - Dichlorobenzene)	-----^c	17,000^b	-----^c	340^b	2	11	*

91-94-1	3,3'-Dichlorobenzidine	13^e	-----^c	280^e	-----^c	0.007^e,f	0.033	1.3
75-34-3	1,1-Dichloroethane	200,000^b	1,700^d	200,000^b	130^b	23^b	110	*
107-06-2	1,2-Dichloroethane (Ethylene dichloride)	63^e	0.70^e	1,400^e	0.99^e	0.02	0.1	*
75-35-4	1,1-Dichloroethylene	18,000^b	1,500^d	1,800^b	1,500^d	0.06	0.3	*
156-59-2	cis-1,2-Dichloroethylene	20,000^b	1,200^d	20,000^b	1,200^d	0.4	1.1	*
156-60-5	trans-1,2-Dichloroethylene	41,000^b	3,100^d	41,000^b	3,100^d	0.7	3.4	*
78-87-5	1,2-Dichloropropane	84^e	23^b	1,800^e	0.50^b	0.03	0.15	*
542-75-6	1,3-Dichloropropene (1,3-Dichloropropylene, cis + trans)	33^e	0.23^e	610^b	0.33^e	0.004^e	0.02	0.005
60-57-1	Dieldrinⁿ	0.4^e	2.2^e	7.8^e	3.1^e	0.004^e	0.02	~~0.0013~~ 0.603
84-66-2	Diethyl phthalate	1,000,000^b	2,000^d	1,000,000^b	2,000^d	470^b	470	*

121-14-2	2,4-Dinitrotoluene	8.4^e	-----^c	180^e	-----^c	0.0008^e,f	0.0008	~~0.013~~ 0.250
606-20-2	2,6-Dinitrotoluene	8.4^e	-----^c	180^e	-----^c	0.0007^e,f	0.0007	~~0.0067~~ 0.260
117-84-0	Di-n-octyl phthalate	41,000^e	10,000^d	4,100^b	10,000^d	10,000^d	10,000^d	*
115-29-7	Endosulfan^o	12,000^b	-----^c	1,200^b	-----^c	18^b	90	*
145-73-3	Endothall^o	41,000^c	-----^c	4,100^b	-----^c	0.4	0.4	NA
72-20-8	Endrin	610^b	-----^c	61^b	-----^c	1	5	*
100-41-4	Ethylbenzene	200,000^b	400^d	20,000^b	58^b	13	19	*
206-44-0	Fluoranthene	82,000^b	-----^c	82,000^b	-----^c	4,300^b	21,000	*
86-73-7	Fluorene	82,000^b	-----^c	82,000^b	-----^c	560^b	2,800	*
76-44-8	Heptachlor	1^e	11^e	28^e	16^e	23	110	*

1024-57-3	Heptachlor epoxide	0.6^e	9.2^e	2.7^b	13^e	0.7	3.3	1.005
118-74-1	Hexachlorobenzene	4^e	1.8^e	78^e	2.6^e	2	11	*
319-84-6	alpha-HCH (alpha-BHC)	0.9^e	1.5^e	20^e	2.1^e	0.0005^e,f	0.003	~~0.002~~ 0.0074
58-89-9	gamma-HCH (Lindane)ⁿ	4^e	-----^c	96^e	-----^c	0.009	0.047	*
77-47-4	Hexachlorocyclopentadiene	14,000^b	16^b	14,000^b	1.1^b	400	2,200^d	*
67-72-1	Hexachloroethane	2,000^b	-----^c	2,000^b	-----^c	0.5^b	2.6	*
193-39-5	Indeno(1,2,3-c,d)pyrene	8^e	-----^c	170^e	-----^c	14	69	*
78-59-1	Isophorone	410,000^b	4,600^d	410,000^b	4,600^d	8^b	8	*
72-43-5	Methoxychlor^o	10,000^b	-----^c	1,000^b	-----^c	160	780	*
74-83-9	Methyl bromide (Bromomethane)	2,900^b	15^b	1,000^b	3.9^b	0.2^b	1.2	*

122-34-9	Simazine^o	10,000^b	-----^c	1,000^b	-----^c	0.04	0.37	NA
100-42-5	Styrene	410,000^b	1,500^d	41,000^b	430^b	4	18	*
127-18-4	Tetrachloroethylene (Perchloroethylene)	110^e	20^e	2,400^e	28^e	0.06	0.3	*
108-88-3	Toluene	410,000^b	650^d	410,000^b	42^b	12	29	*
8001-35-2	Toxapheneⁿ	5.2^e	170^e	110^e	240^e	31	150	*
120-82-1	1,2,4-Trichlorobenzene	20,000^b	3,200^d	2,000^b	920^b	5	53	*
71-55-6	1,1,1-Trichloroethane	-----^c	1,200^d	-----^c	1,200^d	2	9.6	*
79-00-5	1,1,2-Trichloroethane	8,200^b	1,800^d	8,200^b	1,800^d	0.02	0.3	*
79-01-6	Trichloroethylene	520^e	8.9^e	1,200^b	12^e	0.06	0.3	*
108-05-4	Vinyl acetate	1,000,000^b	1,600^b	200,000^b	10^b	170^b	170	*

7782-41-4	Fluoride	120,000^b	-----^c	12,000^b	-----^c	4.0^m	4.0^m	*
15438-31-0	Iron	-----^c	-----^c	-----^c	-----^c	5.0^m	5.0^m	*
7439-92-1	Lead	400^k	-----^c	400^k	-----^c	0.0075^m	0.1^m	*
7439-96-5	Manganese	96,000^b	91,000^b	9,600^b	8,700^b	0.15^m	10.0^m	*
7439-97-6	Mercury^l,n,s	610^b	540,000^b	61^b,s	52,000^b	0.002^m	0.01^m	*
7440-02-0	Nickel^l	41,000^b	21,000^e	4,100^b	440,000^e	0.1^m	2.0^m	*
14797-55-8	Nitrate as N^p	1,000,000^b	-----^c	330,000^b	-----^c	10.0^q	100^q	*
7782-49-2	Selenium^l,n	10,000^b	-----^c	1,000^b	-----^c	0.05^m	0.05^m	*

"*" indicates that the ADL is less than or equal to the specified remediation objective.

Chemical Name and Soil Remediation Objective Notations (2nd, 5th thru 8th Columns)

Section 742.Table C: pH Specific Soil Remediation Objectives for Inorganics and Ionizing Organics for the Soil Component of the Groundwater Ingestion Route (Class I Groundwater)

Inorganics
Antimony	5	5	5	5	5	5	5	5	5	5	5
Arsenic	25	26	27	28	29	29	29	30	31	32	33
Barium	260	490	850	1,200	1,500	1,600	1,700	1,800	2,100	__^a	__^a
Beryllium	1.1	2.1	3.4	6.6	22	63	140	1,000	8,000	__^a	__^a
Cadmium	1.0	1.7	2.7	3.7	5.2	7.5	11	59	430	__^a	__^a
Chromium (+6)	70	62	54	46	40	38	36	32	28	24	21
Copper	330	580	2,100	11,000	59,000	130,000	200,000	330,000	330,000	__^a	__^a
Cyanide	40	40	40	40	40	40	40	40	40	40	40
Mercury	0.01	0.01`	0.03	0.15	0.89	2.1	3.3	6.4	8.0	__^a	__^a
Nickel	20	36	56	76	100	130	180	700	3,800	__^a	__^a
Selenium	24	17	12	8.8	6.3	5.2	4.5	3.3	2.4	1.8	1.3
Silver	0.24	0.33	0.62	1.5	4.4	8.5	13	39	110	__^a	__^a

Thallium	1.6	1.8	2.0	2.4	2.6	2.8	3.0	3.4	3.8	4.4	4.9
Vanadium	980	980	980	980	980	980	980	980	980	980	980
Zinc	1,000	1,800	2,600	3,600	5,100	6,200	7,500	16,000	53,000	__^a	__^a
Organics

Section 742.Table D: pH Specific Soil Remediation Objectives for Inorganics and Ionizing Organics for the Soil Component of the Groundwater Ingestion Route (Class II Groundwater)

Inorganics
Antimony	20	20	20	20	20	20	20	20	20	20	20
Arsenic	100	100	100	110	110	120	120	120	120	130	130
Barium	260	490	850	1,200	1,500	1,600	1,700	1,800	2,100	__^a	__^a
Beryllium	140	260	420	820	2,800	7,900	17,000	130,000	1,000,000	__^a	__^a
Cadmium	10	17	27	37	52	75	110	590	4,300	__^a	__^a
Chromium (+6)	No Data	No Data	No Data	No Data	No Data	No Data	No Data	No Data	No Data	No Data	No Data
Copper	330	580	2,100	11,000	59,000	130,000	200,000	330,000	330,000	__^a	__^a
Cyanide	120	120	120	120	120	120	120	120	120	120	120
Mercury	0.05	0.06	0.14	0.75	4.4	10	16	32	40	__^a	__^a
Nickel	400	730	1,100	1,500	2,000	2,600	3,500	14,000	76,000	__^a	__^a
Selenium	24	17	12	8.8	6.3	5.2	4.5	3.3	2.4	1.8	1.3
Thallium	16	18	20	24	26	28	30	34	38	44	49
Zinc	2,000	3,600	5,200	7,200	10,000	12,000	15,000	32,000	110,000	__^a	__^a

Organics
Benzoic Acid	440	420	410	400	400	400	400	400	400	400	400
2-Chlorophenol	20	20	20	20	20	20	19	3.6	3.1	2.2	1.5
2,4-Dichlorophenol	1.0	1.0	1.0	1.0	1.0	1.0	1.0	0.86	0.69	0.56	0.48
Dinoseb	84	45	19	8.2	4.3	3.4	3.1	2.7	2.5	2.5	2.5
Pentachlorophenol	2.7	1.6	0.75	0.33	0.18	0.15	0.12	0.11	0.10	0.10	0.10
2,4,5-TP (Silvex)	130	79	62	57	55	55	55	55	55	55	55
2,4,5-Trichlorophenol	2,000	2,000	1,900	1,800	1,600	1,400	1,200	640	64	36	26
2,4,6-Trichlorophenol	1.9	1.8	1.7	1.4	1.0	0.77	0.13	0.09	0.07	0.07	0.07

(Source: Amended in R00-19(B) at 24 Ill. Reg. _____, effective __________________)

Section 742.TABLE E: Tier 1 Groundwater Remediation Objectives for the Groundwater Component of the Groundwater Ingestion Route

Section 742.TABLE F: Values Used to Calculate the Tier 1 Soil Remediation Objectives for the Soil Component of the Groundwater Ingestion Route

Chemical Abstracts Service (CAS) registry number. This number in the format xxx-xx-x, is unique for each chemical and allows efficient searching on computerized data bases.

^aSoil Remediation objectives are determined pursuant to 40 CFR 761.120, as incorporated by reference at Section 732.104 (the USEPA "PCB Spill Cleanup Policy"), for most sites; persons remediating sites should consult with BOL if calculation of Tier 2 soil remediation objectives is desired.

Section 742.TABLE I: K_oc Values for Ionizing Organics as a Function of pH (cm³/g or L/kg or cm3water/g _soil )

Section 742.TABLE J: Values to be Substituted for K _d or K_s ~~k_s~~ when Evaluating Inorganics as a Function of pH (cm3/g or L/kg or cm³_water/g_soil)

I, Dorothy M. Gunn, Clerk of the Illinois Pollution Control Board, do hereby certify that the above opinion and order was adopted on the 27^th day of July, 2000 by a vote of 6-0.

Nn	0.01	0.05
3	0.753	0.767
4	0.687	0.748
5	0.686	0.762
6	0.713	0.788
7	0.730	0.803
8	0.749	0.818
9	0.764	0.829
10	0.781	0.842
11	0.792	0.850
12	0.805	0.859
13	0.814	0.866
14	0.825	0.874
15	0.835	0.881
16	0.844	0.887
17	0.851	0.892
18	0.858	0.897
19	0.863	0.901
20	0.868	0.905
21	0.873	0.908
22	0.878	0.911
23	0.881	0.914
24	0.884	0.916
25	0.888	0.918
26	0.891	0.920
27	0.894	0.923
28	0.896	0.924
29	0.898	0.926
30	0.900	0.927
31	0.902	0.929
32	0.904	0.930
33	0.906	0.931
34	0.908	0.933
35	0.910	0.934

Chemical Name	Counties Within Metropolitan Statistical Areas^a (mg/kg)	Counties Outside Metropolitan Statistical Areas (mg/kg)
Nickel	18.0	13.0
Potassium	1,268	1,100
Selenium	0.48	0.37
Silver	0.55	0.50
Sodium	130	130.0
Sulfate	85.5	110
Sulfide	3.1	2.9
Thallium	0.32	0.42
Vanadium	25.2	25.0
Zinc	95.0	60.2

Chemical	Class I Groundwater Remediation Objective (mg/l)	1 in 1,000,000 Cancer Risk Concentration (mg/l)	ADL (mg/l)

Aldrin	~~0.00004~~0.014	0.000005	~~0.00004~~0.014
Benzo(a)pyrene	0.0002	0.0000012	0.00023
Bis(2-chloroethyl)ether	0.01	0.000077	0.01
Bis(2-ethylhexyl)phthalate	0.006	0.0061	0.0027
Carbon Tetrachloride	0.005	0.00066	~~0.00003~~0.0001
Chlordane	0.002	0.000066	0.00014
DDD	0.014	0.00023	0.014
DDE	0.01	0.00023	0.01
DDT	0.006	0.00023	0.006
Dibenzo(a,h)anthracene	0.0003	0.000012	0.0003
1,2-Dibromo-3-chloropropane	0.0002	0.000061	~~0.0002~~0.001
1,2-dibromoethane	0.00005	0.0000010	~~0.00005~~0.001
3,3'-Dichlorobenzidine	0.02	0.00019	0.02
1,2-Dichloroethane	0.005	0.00094	0.0003
Dieldrin	~~0.00002~~0.009	0.0000053	~~0.00002~~0.009
2,6-Dinitrotoluene	0.00031	0.0001	0.00031
Heptachlor	0.0004	0.000019	~~0.00003~~0.013
Heptachlor epoxide	0.0002	0.0000094	~~0.00032~~0.015
Hexachlorobenzene	0.00006	0.000053	0.00006
Alpha-HCH	~~0.00003~~0.00011	0.000014	~~0.00003~~0.000111
Tetrachloroethylene	0.005	0.0016	~~0.0001~~0.0004
Toxaphene	0.003	0.000077	0.00086
Vinyl chloride	0.002	0.000045	~~0.00006~~0.0002

Ionizable Organics

N-Nitrosodi-n-propylamine	~~0.01~~0.0018	0.000012	~~0.01~~0.0018
Pentachlorophenol	0.001	0.00071	~~0.001~~0.000076
2,4,6-Trichlorophenol	0.01	0.007	0.01

Inorganics Organics

Arsenic	0.05	0.000057	0.001
Beryllium	0.004	0.00002	0.004

CAS No.	Chemical Name	Ingestion (mg/kg)	Inhalation (mg/kg)	Class I (mg/kg)	Class II (mg/kg)	ADL (mg/kg)
1330-20-7	Xylenes (total)	160,000^b	320^d	150	150	*
	Ionizable Organics
65-85-0	Benzoic Acid	310,000^b	---^c	400^b,i	400ⁱ	*
95-57-8	2-Chlorophenol	390^b	53,000^d	4^b,i	4ⁱ	*
120-83-2	2,4-Dichlorophenol	230^b	---^c	1^b,i	1ⁱ	*
51-28-5	2,4-Dinitrophenol	160^b	---^c	0.2^b,f	0.2	3.3
88-85-7	Dinoseb^o	78^b	---^c	0.34^b,i	3.4ⁱ	*
87-86-5	Pentachlorophenol	3^e,j	---^c	0.03^f,i	0.14ⁱ	~~2.4~~*
93-72-1	2,4,5-TP (Silvex)	630^b	---^c	11ⁱ	55ⁱ	*
95-95-4	2,4,5-Trichlorophenol	7,800^b	---^c	270^b,i	1,400ⁱ	*
88-06-2	2,4,6 Trichlorophenol	58^e	200^e	0.2^e,f,i	0.77ⁱ	~~0.43~~0.66

CAS No.	Chemical Name	Ingestion (mg/kg)	Inhalation (mg/kg)	Class I (mg/L)	Class II (mg/L)	ADL (mg/kg)
	Inorganics
7440-36-0	Antimony	31^b	---^c	0.006^m	0.024^m	*
7440-38-2	Arsenic^l,n	~~0.4^e,~~^t	750^e	0.05^m	0.2^m	*
7440-39-3	Barium	5,500^b	690,000^b	2.0^m	2.0^m	*
7440-41-7	Beryllium	~~0.1^e,t~~160^b	1,300^e	0.004^m	0.5^m	*
7440-42-8	Boron	7,000^b	---^g	2.0^m	2.0^m	*
7440-43-9	Cadmium^l,n	78^{b, r}	1,800^e	0.005^m	0.05^m	*
16887-00-6	Chloride	---^c	---^c	200^m	200^m	*
7440-47-3	Chromium, total	~~390~~ 230^b	270^e	0.1^m	1.0^m	*
16065-83-1	Chromium, ion, trivalent	~~78,000~~120,000^b	---^c	---^g	---^g	*
18540-29-9	Chromium, ion, hexavalent	~~390~~ 230^b	270^e	---	---	*
7440-48-4	Cobalt	4,700^b	---^c	1.0^m	1.0^m	*

^a Soil remediation objectives based on human health criteria only.
^b Calculated values correspond to a target hazard quotient of 1.
^c No toxicity criteria available for the route of exposure.
^d Soil saturation concentration (C _[[satt]) = the concentration at which the absorptive limits of the soil particles, the solubility limits of the available soil moisture, and saturation of soil pore air have been reached. Above the soil saturation concentration, the assumptions regarding vapor transport to air and/or dissolved phase transport to groundwater (for chemicals which are liquid at ambient soil temperatures) have been violated, and alternative modeling approaches are required.
^e Calculated values correspond to a cancer risk level of 1 in 1,000,000.
^f Level is at or below Contract Laboratory Program required quantitation limit for Regular Analytical Services (RAS).
^g Chemical-specific properties are such that this route is not of concern at any soil contaminant concentration.
^h A preliminary goal of 1 ppm has been set for PCBs based on Guidance on Remedial Actions for Superfund Sites with PCB Contamination, EPA/540G-90/007, and on USEPA efforts to manage PCB contamination. See 40 CFR 761.120 - USEPA "PCB Spill Cleanup Policy." This regulation goes on to say that the remediation goal for an unrestricted area is 10 ppm and 25 ppm for a restricted area, provided both have at least 10 inches of clean cover. 40 CFR 761 contains applicability requirements and methodologies for the development of PCB remediation objectives. Requests for approval of a Tier 3 evaluation must address the applicability of 40 CFR 761.
ⁱ Soil remediation objective for pH of 6.8. If soil pH is other than 6.8, refer to Appendix B, Tables C and D of this Part.
^j Ingestion soil remediation objective adjusted by a factor of 0.5 to account for dermal route.
^k A preliminary remediation goal of 400 mg/kg has been set for lead based on Revised Interim Soil Lead Guidance for CERCLA Sites and RCRA Corrective Action Facilities, OSWER Directive #9355.4-12.
^l Potential for soil-plant-human exposure.
^m The person conducting the remediation has the option to use: 1) TCLP or SPLP test results to compare with the remediation objectives listed in this Table; or 2) the total amount of contaminant in the soil sample results to compare with pH specific remediation objectives listed in Appendix B, Table C or D of this Part. (See Section 742.510.) If the person conducting the remediation wishes to calculate soil remediation objectives based on background concentrations, this should be done in accordance with Subpart D of this Part.
ⁿ The Agency reserves the right to evaluate the potential for remaining contaminant concentrations to pose significant threats to crops, livestock, or wildlife.
^o For agrichemical facilities, remediation objectives for surficial soils which are based on field application rates may be more appropriate for currently registered pesticides. Consult the Agency for further information.
^p For agrichemical facilities, soil remediation objectives based on site-specific background concentrations of Nitrate as N may be more appropriate. Such determinations shall be conducted in accordance with the procedures set forth in Subparts D and I of this Part.
^qThe TCLP extraction must be done using water at a pH of 7.0.
^r Value based on dietary Reference Dose.
^s ~~Value based on Reference Dose for Mercuric chloride (CAS No. 7487-94-7).~~ Value for Ingestion based on Reference Dose for Mercuric chloride (CAS No. 7487-94-7); value for Inhalation based on Reference Concentration for elemental Mercury (CAS No. 7439-97-6).

^u Value based on Reference Dose for thallium sulfate (CAS No. 7446-18-6).


(Source: Amended in R00-19(B) at 24 Ill. Reg. ____, effective_______________)

67-66-3	Chloroform	940^e	0.54^e	2,000^b	0.76^e	0.6	2.9	*
218-01-9	Chrysene	780^e	-----^c	17,000^e	-----^e	160	800	*
94-75-7	2,4-D^o	20,000^b	-----^c	2,000^b	-----^c	1.5	7.7	*

91-20-3	Naphthalene	~~82,000~~41,000^b	~~-----^c~~270^b	~~8,200~~4,100^b	~~-----^c~~1.8^b	8412^b	~~420~~ 18	*
98-95-3	Nitrobenzene	1,000^b	140^b	1,000^b	9.4^b	0.1^b,f	0.1	0.26

1918-02-1	Picloram^o	140,000^b	-----^c	14,000^b	-----^c	2	20	NA
1336-36-3	Polychlorinated biphenyls (PCBs)ⁿ	1 ~~1; 10; 25~~^h	-----^c,h	1^h	-----^c,h	-----^h	-----^h	*
129-00-0	Pyrene	61,000^b	-----^c	61,000^b	-----^c	4,200^b	21,000	*

75-01-4	Vinyl chloride	3^e	0.06^e	65^e	0.08^e	0.01^f	0.07	*
108-38-3	m-Xylene	1,000,000	420^d	410,000^b	420^d	210	210	*

7440-22-4	Silver	10,000^b	-----^c	1,000^b	-----^c	0.05^m	-----	*
14808-79-8	Sulfate	-----^c	-----^c	-----^c	-----^c	400^m	400^m	*
7440-28-0	Thallium	160^b,u	-----^c	160^b,u	-----^c	0.002^m	0.02^m	*

7440-62-2	Vanadium	14,000^b	-----^c	1,400^b	-----^c	0.049^m	0.1^m	*
7440-66-6	Zinc^l	610,000^b	-----^c	61,000^b	-----^c	5.0^m	10^m	*

108-90-7	Chlorobenzene (Monochlorobenzene)	0.1^c	0.5^c
124-48-1	Chlorodibromomethane (Dibromochloromethane)	0.14	0.14
67-66-3	Chloroform	~~0.00002~~0.0002^a	~~0.0001~~0.001
218-01-9	Chrysene	0.0015^a	0.0075
94-75-7	2,4-D	0.07^c	0.35^c

75-99-0	Dalapon	0.2^c	2.0^c
72-54-8	DDD	~~0.00011~~0.014^a	~~0.00055~~0.07
72-55-9	DDE	~~0.00004~~0.01^a	~~0.0002~~0.05
50-29-3	DDT	~~0.00012~~0.006^a	~~0.0006~~0.03
53-70-3	Dibenzo(a,h)anthracene	0.0003^a	0.0015
96-12-8	1,2-Dibromo-3-chloropropane	0.0002^c	0.0002^c
106-93-4	1,2-Dibromoethane (Ethylene dibromide)	0.00005^a,c	0.0005^c
84-74-2	Di-n-butyl phthalate	0.7	3.5
95-50-1	1,2-Dichlorobenzene (o - Dichlorobenzene)	0.6^c	1.5^c
106-46-7	1,4-Dichlorobenzene (p - Dichlorobenzene)	0.075^c	0.375^c
91-94-1	3,3'-Dichlorobenzidine	0.02^a	0.1
75-34-3	1,1-Dichloroethane	0.7	3.5
107-06-2	1,2-Dichloroethane (Ethylene dichloride)	0.005^c	0.025^c
75-35-4	1,1-Dichloroethylene^b	0.007^c	0.035^c
156-59-2	cis-1,2-Dichloroethylene	0.07^c	0.2^c
156-60-5	trans-1,2-Dichloroethylene	0.1^c	0.5^c
78-87-5	1,2-Dichloropropane	0.005^c	0.025^c
542-75-6	1,3-Dichloropropene (1,3-Dichloropropylene, cis + trans)	0.001^a	0.005

60-57-1	Dieldrin	~~0.00002~~0.009^a	~~0.0001~~0.045
84-66-2	Diethyl phthalate	5.6	5.6
121-14-2	2,4-Dinitrotoluene^a	0.00002^a	0.00002
606-20-2	2,6-Dinitrotoluene^a	~~0.0001~~0.00031^a	~~0.0001~~0.00031
88-85-7	Dinoseb	0.007^c	0.07^c
117-84-0	Di-n-octyl phthalate	0.14	0.7
115-29-7	Endosulfan	0.042	0.21
145-73-3	Endothall	0.1^c	0.1^c
72-20-8	Endrin	0.002^c	0.01^c

100-41-4	Ethylbenzene	0.7^c	1.0^c
206-44-0	Fluoranthene	0.28	1.4
86-73-7	Fluorene	0.28	1.4
76-44-8	Heptachlor	0.0004^c	0.002^c
1024-57-3	Heptachlor epoxide	0.0002^c	0.001^c
118-74-1	Hexachlorobenzene	0.00006^a	0.0003
319-84-6	alpha-HCH (alpha-BHC)	~~0.00003~~0.00011^a	~~0.00015~~0.00055
58-89-9	gamma-HCH (Lindane)	0.0002^c	0.001^c
77-47-4	Hexachlorocyclopentadiene	0.05^c	0.5^c
67-72-1	Hexachloroethane	0.007	0.035
193-39-5	Indeno(1,2,3-c,d)pyrene	0.00043^a	0.00215
78-59-1	Isophorone	1.4	1.4
72-43-5	Methoxychlor	0.04^c	0.2^c
74-83-9	Methyl bromide (Bromomethane)	0.0098	0.049
1634-04-4	Methyl tert-butyl ether	0.07	0.07
75-09-2	Methylene chloride (Dichloromethane)	0.005^c	0.05^c
91-20-3	Naphthalene²	~~0.025~~ 0.14	~~0.039~~0.22
98-95-3	Nitrobenzene²^b	0.0035	0.0035

86-30-6	N-Nitrosodiphenylamine	~~0.01~~0.0032^a	~~0.05~~0.016
621-64-7	N-Nitrosodi-n-propylamine	~~0.01~~0.0018^a	~~0.01~~0.0018
87-86-5	Pentachlorophenol	0.001^a,c	0.005^c
108-95-2	Phenol	0.1^c	0.1^c
1918-02-1	Picloram	0.5^c	5.0^c
1336-36-3	Polychlorinated biphenyls (PCBs)ⁿ	0.0005^c	0.0025^c
129-00-0	Pyrene	0.21	1.05
122-34-9	Simazine	0.004^c	0.04^c
100-42-5	Styrene	0.1^c	0.5^c
93-72-1	2,4,5-TP (Silvex)	0.05^c	0.25^c
127-18-4	Tetrachloroethylene (Perchloroethylene)	0.005^c	0.025^c
108-88-3	Toluene	1.0^c	2.5^c
8001-35-2	Toxaphene	0.003^c	0.015^c
120-82-1	1,2,4-Trichlorobenzene	0.07^c	0.7^c
71-55-6	1,1,1-Trichloroethane²^b	0.2^c	1.0^c
79-00-5	1,1,2-Trichloroethane	0.005^c	0.05^c
79-01-6	Trichloroethylene	0.005^c	0.025^c

7439-96-5	Manganese	0.15^c	10.0^c
7439-97-6	Mercury	0.002^c	0.01^c
7440-02-0	Nickel	0.1^c	2.0^c
14797-55-8	Nitrate as N	10.0^c	100^c
7782-49-2	Selenium	0.05^c	0.05^c
7440-22-4	Silver	0.05^c	---
14808-79-8	Sulfate	400^c	400^c

^a~~The groundwater Health Advisory concentration is equal to ADL for carcinogens~~.The groundwater remediation objective is equal to the ADL for carcinogens according to the procedures specified in 35 Ill. Adm. Code 620.
^b Oral Reference Dose and/or Reference Concentration under review by USEPA. Listed values subject to change.
^c Value listed is also the Groundwater Quality Standard for this chemical pursuant to 35 Ill. Adm. Code 620.410 for Class I Groundwater or 35 Ill. Adm. Code 620.420 for Class II Groundwater.

60-57-1	Dieldrin	5.0E-6^b	2.5E-5
84-66-2	Diethyl phthalate	30^b	30
121-14-2	2,4-Dinitrotoluene	0.0001^b	0.0001
606-20-2	2,6-Dinitrotoluene	0.0001	0.0001
88-85-7	Dinoseb	0.007^c	0.07^c
117-84-0	Di-n-octyl phthalate	0.7^b	3.5
115-29-7	Endosulfan	0.2^b	1.0
145-73-3	Endothall	0.1^c	0.1^c
72-20-8	Endrin	0.002^c	0.01^c
100-41-4	Ethylbenzene	0.7^c	1.0^c
206-44-0	Fluoranthene	1.0^b	5.0
86-73-7	Fluorene	1.0^b	5.0
76-44-8	Heptachlor	0.0004^c	0.002^c
1024-57-3	Heptachlor epoxide	0.0002^c	0.001^c
118-74-1	Hexachlorobenzene	0.001^b	0.005
319-84-6	alpha-HCH (alpha-BHC)	1.0E-5^b	5.0E-5
58-89-9	gamma-HCH (Lindane)	0.0002^c	0.001^c
77-47-4	Hexachlorocyclopentadiene	0.05^c	0.5^c
67-72-1	Hexachloroethane	0.007	0.035
193-39-5	Indeno(1,2,3-c,d)pyrene	0.0001^b	0.0005
78-59-1	Isophorone	1.4	1.4
72-43-5	Methoxychlor	0.04^c	0.2^c
74-83-9	Methyl bromide (Bromomethane)	0.05^b	0.25
1634-04-4	Methyl tert-butyl ether	0.07	0.07
75-09-2	Methylene chloride (Dichloromethane)	0.005^c	0.05^c
91-20-3	Naphthalene	~~1.0^b~~0.14	~~5.0~~0.22
98-95-3	Nitrobenzene	0.02^b	0.02

^aThe Equation S17 is used to calculate the Soil Remediation Objective for the Soil Component of the Groundwater Ingestion Route; this equation requires calculation of the Target Soil Leachate Concentration (C_w) from Equation S18: C_w = DF x GW_obj.
^b Value listed is the Water Health Based Limit (HBL) for this chemical from Soil Screening Guidance: User’s Guide, incorporated by reference at Section 742.210~~; for carcinogens,~~. The ~~the~~ HBL is equal to the non-zero MCLG (if available); the MCL (if available); or, for carcinogens, a cancer risk of 1.0E-6, and for noncarcinogens is equal to a Hazard Quotient of 1.0. NOTE: These GW_obj concentrations are not equal to the Tier 1 Groundwater Remediation Objectives for the Direct Ingestion of Groundwater Component of the Groundwater Ingestion Route, listed in Section 742.Appendix B, Table E.
^c Value listed is also the Groundwater Quality Standard for this chemical pursuant to 35 Ill. Adm. Code 620.410 for Class I Groundwater or 35 Ill. Adm. Code 620.420 for Class II Groundwater.

Equations for Soil Ingestion Exposure Route	Remediation Objectives for Noncarcinogenic Contaminants (mg/kg)	S1
	Remediation Objectives for Carcinogenic Contaminants - Residential (mg/kg)	S2
	Remediation Objectives for Carcinogenic Contaminants - Industrial/ Commercial, Construction Worker (mg/kg)	S3
Equations for Inhalation Exposure Route (~~Volatiles~~Organic Contaminants)	Remediation Objectives for Noncarcinogenic Contaminants - Residential, Industrial/Commercial (mg/kg)	S4

	Remediation Objectives for Carcinogenic Contaminants - Construction Worker (mg/kg)		S7
	Equation for Derivation of the Volatilization Factor - Residential, Industrial/ Commercial, VF (m³/kg)		S8
	Equation for Derivation of the Volatilization Factor - Construction Worker, VF ¢ (m³/kg)		S9
	Equation for Derivation of Apparent Diffusivity, D_A (cm²/s)		S10

Equations for Inhalation Exposure Route (Fugitive Dusts)	Remediation Objectives for Noncarcinogenic Contaminants - Residential, Industrial/Commercial (mg/kg)	S11
	Remediation Objectives for Noncarcinogenic Contaminants - Construction Worker (mg/kg)	S12
	Remediation Objectives for Carcinogenic Contaminants - Residential, Industrial/ Commercial (mg/kg)	S13
	Remediation Objectives for Carcinogenic Contaminants - Construction Worker (mg/kg)	S14
	Equation for Derivation of Particulate Emission Factor, PEF (m³/kg)	S15

	Groundwater Remediation Objective for Carcinogenic Contaminants, GW_obj (mg/L)		S23
	Total Soil Porosity, h (L_pore/L_soil)		S24
	Equation for Estimation of Mixing Zone Depth, d (m)		S25
Mass-Limit Equations for Inhalation Exposure Route and Soil Component of the Groundwater Ingestion Exposure Route	Mass-Limit Volatilization Factor for the Inhalation Exposure Route - Residential, Industrial/ Commercial, VF (m³/kg)	NOTE: This equation may be used when ~~area and depth of contaminant source are~~ vertical thickness of contamination is known or can be estimated reliably.	S26
	Mass-Limit Volatilization Factor for Inhalation Exposure Route - Construction Worker, VF ¢ - (m³/kg)		S27

Symbol	Parameter	Units	Source	Parameter Value(s)
AT	Averaging Time for Noncarcinogens in Ingestion Equation	yr		Residential = 6 Industrial/Commercial = 25 Construction Worker = 0.115
AT	Averaging Time for Noncarcinogens in Inhalation Equation	yr		Residential = 30 Industrial/Commercial = 25 Construction Worker = 0.115
AT_c	Averaging Time for Carcinogens	yr	SSL	70
BW	Body Weight	kg		Residential = 15, noncarcinogens 70, carcinogens Industrial/Commercial = 70 Construction Worker = 70
C_sat	Soil Saturation Concentration	mg/kg	Appendix A, Table A or Equation S29 in Appendix C, Table A	Chemical-Specific or Calculated Value
C_w	Target Soil Leachate Concentration	mg/L	Equation S18 in Appendix C, Table A	Groundwater Standard, Health Advisory concentration, or Calculated Value
d	Mixing Zone Depth	m	SSL or Equation S25 in Appendix C, Table A	2 m or Calculated Value
d_a	Aquifer Thickness	m	Field Measurement	Site-Specific

^{a HEAST = Health Effects Assessment Summary Tables. USEPA, Office of Solid Waste and Emergency Response. EPA/SQO/R-95/036. Updated Quarterly.}

	Volatilization Factor for Surficial Soils Regarding Particulates, VF_p (kg/m³)	R5
	Effective Diffusion Coefficient in Soil Based on Vapor-Phase Concentration D_s^eff (cm²/s)	R6
Equations for the ambient vapor inhalation (outdoor) route fromsubsurface soils	Remediation Objectives for Carcinogenic Contaminants (mg/kg)	R7
	Remediation Objectives for Non-carcinogenic Contaminants (mg/kg)	R8

	Transverse Dispersivity, a _y (cm)		R17
	Vertical Dispersivity, a _z (cm)		R18
	Specific Discharge, U (cm/d)		R19
	Soil-Water Sorption Coefficient, k_s		R20
	Volumetric Air Content in Vadose Zone Soils, q _as (cm³_air/cm³_soil)		R21
	Volumetric Water Content in Vadose Zone Soils, q _ws (cm³_water/cm³_soil)		R22
	Total Soil Porosity, q _T (cm³/cm³_soil)		R23

D^air	Diffusion Coefficient in Air	cm²/s	Appendix C, Table E	Chemical-Specific
D^water	Diffusion Coefficient in Water	cm²/s	Appendix C, Table E	Chemical-Specific
D_s^eff	Effective Diffusion Coefficient in Soil Based on Vapor-Phase Concentration	cm²/s	Equation R6 in Appendix C, Table C	Calculated Value
ED	Exposure Duration	yr	RBCA	Residential = 30 Industrial/Commercial = 25 Construction Worker = 1
EF	Exposure Frequency	d/yr	RBCA	Residential = 350 Industrial/Commercial = 250 Construction Worker = 30
erf	Error Function	unitless	Appendix C, Table G	Mathematical Function

I	Infiltration Rate	cm/yr	RBCA	30
IR_air	Daily Outdoor Inhalation Rate	m³/d	RBCA	20
IR_soil	Soil Ingestion Rate	mg/d	RBCA	Residential = 100 Industrial/Commercial = 50 Construction Worker = 480
IR_w	Daily Water Ingestion Rate	L/d	RBCA	Residential = 2 Industrial/Commercial = 1

k_s (ionizing organics)	Soil Water Sorption Coefficient	cm³_water/g_soil	Equation R20 in Appendix C, Table C	Chemical and pH-Specific (See Appendix C, Table I)
k_s (inorganics)	Soil Water Sorption Coefficient	cm³_water/g_soil	Appendix C, Table J	Chemical and pH-Specific
L_s	Depth to Subsurface Soil Sources	cm	RBCA	100
LF_sw	Leaching Factor	(mg/L_water)/ (mg/kg_soil)	Equation R14 in Appendix C, Table C	Calculated Value
M	Soil to Skin Adherence Factor	mg/cm²	RBCA	0.5

Pe	Particulate Emission Rate	g/cm²-s	RBCA	6.9 · 10^-14
RAF_d	Dermal Relative Absorption Factor	unitless	RBCA	0.5
RAF_d (PNAs)	Dermal Relative Absorption Factor	unitless	RBCA	0.05
RAF_d (inorganics)	Dermal Relative Absorption Factor	unitless	RBCA	0
RAF_o	Oral Relative Absorption Factor	unitless	RBCA	1.0

RBSL_air	Carcinogenic Risk-Based Screening Level for Air	ug/m³	Equation R9 in Appendix C, Table C	Chemical-, Media-, and Exposure Route-Specific
RBSL_air	Noncarcinogenic Risk-Based Screening Level for Air	ug/m³	Equations R10 in Appendix C, Table C	Chemical-, Media-, and Exposure Route-Specific
RfD_i	Inhalation Reference Dose	mg/kg-d	IEPA (IRIS/HEAST^a)	Toxicological-Specific
RfD_o	Oral Reference Dose	mg/(kg-d)	IEPA (IRIS/HEAST^a)	Toxicological-Specific (Note: for Construction Worker use subchronic reference doses)
SA	Skin Surface Area	cm²/d	RBCA	3,160
